HEPA Aire PAS2400 Abatement Technologies | Portable Air Scrubber

Built-in Stair Climber

The built-in stair climber further enhances portability by making it easier to go up or down stairs. The upper pre-filter module can also be detached and hand-carried to further lighten the load.

‘Zero Bypass’ Design and True HEPA Filter

A unique cabinet design and a true high-capacity, IEST-compliant HEPA filter help ensure that the HEPA-Aire PAS2400 exhausts 99.97%+ efficiency air out of the work area, job after job, month after month.

Portability - The upright, two-module design with built-in transport dolly enhance the mobility and maneuverability of the PAS2400 and its ability to operate in tight spaces
Power - The custom-designed, high-speed motor and AT Gold blower allow the Abatement PAS2400 to produce up to 60% more vacuum power than other 120 VAC systems
Economy - The high dirt-holding capacity of the PAS2400 pre-filters and long life non-electrostatic HEPA filter extend the useful life of the filters and reduce replacement filter costs
Efficiency - True 99.97%-certified HEPA filter retains its original 99.97%+ efficiency, even after hundreds of hours of operation
User-Friendly Controls - A complete array of convenient controls enables users to continuously monitor the operating status of the PAS2400
Safety First - ETL/ETLc-certified to conform to UL507 and CSA 22.2 safety standards
Export Model Available - The 230V/50-60Hz PAS2400TF model is designed specifically for overseas users

• Speed control switch
• Green ‘Unit On’ indicator lamp
• ‘Replace Pre-filter’ indicator lamp
• ‘Replace HEPA’ indicator lamp
• GFCI-protected
• Hour meter

All Abatement HEPA-CARE units have been tested by a Nationally Recognized Testing Laboratory (NRTL) and carry the marks certifying that they comply with applicable OSHA, UL and CSA electrical safety standards. Filters meet UL900 flammability standards.

• Rated Airflow*: 700-2,100 cfm
• Air Changes Per Hour: 6 ACH in areas up to 18,000-21,000 ft³
• Net Weight with Filters: 170 pounds
• Dimensions (L x W x H): 31.50”L x 25.25”W x 49.75”H
• Power Supply Requirements: 120 VAC, 60Hz, 15 amps
• Normal Operating Current: 12 amps or less (safe for 15A circuits)
• Electrical Safety: NRTL-certified to comply with UL Std. 507 & CAN/CSA Std. #C22.2 No. 113-M1984 for electrical safety
• Motor: High-efficiency type, 3,450 RPM, 1.5 HP
• AT Gold Blower: Anodized-Aluminum, 5.5” peak static lift
• Controls: Off/High/Low speed selector switch, green power indicator lamp, separate amber ‘Replace Pre-filter’ and ‘replace HEPA’ lamps, hour meter, resettable pop-out 12A circuit breaker
• Cabinet Material: 20 gauge stainless steel construction with solid, aircraft-type rivets
• Built-in Dolly: Two-wheel dolly with 10” solid, non-marking rubber rear wheels, 360° swivel front casters and a secure top handle for easy movement & control
• Easy to Replace Pre-Filters: Hinged and latched pre-filter access door with a full perimeter gasket seal to protect against dirty-air bypass
• Pre-Filter Mounting: Separate slide-in compartments for up to 3 pre-filter stages
  Filters:
• Stage 1 pre-filter - Inexpensive, 1”-deep FIBER-TRAPPER® 1.0 pre-filter for larger particulates (100+ microns); can be washed & reused, or treated as a disposable
• Stage 2 pre-filter - Pleated, 2”-deep filter for medium-sized particulates (10-100 microns)
• Stage 3 pre-filter (not included) - High-capacity 2""-deep VAPOR-LOCK® carbon filter for gases & odors
• Final stage HEPA filter - High-capacity, for 0.1-10 micron particles, certified test efficiency of 99.97% or higher @ 0.3 microns, metal-frame
• Inlet/Outlet Manifold - Molded slide-in plastic manifold for attaching 12” inlet or outlet ducting (one included)
